Hlau -Seated Npauj Npaim Valve Rau Kev Pabcuam Nqus Tsev

Cov Hlau -Seated Npauj Npaim Valve rau Kev Pabcuam Nqus Tsev muab xoom- leakage bidirectional cais rau sub- atmospheric thiab siab - cov ntawv thov nqus dej ua haujlwm mus txog 1 × 10⁻⁶ mbar·L / s. Featuring triple -offset torque-seed mechanics paired with precision-av alloy sealing khub niam txiv, qhov kev tsim no tiv thaiv huab cua nkag mus rau hauv lub sijhawm thaum ua kom muaj kev kub ntxhov ceev ceev, kev hloov siab sib txawv, thiab feem ntau- cov txheej txheem ntws.

Mass Spectrometer Verified Seat Tightness:Cov ntaub ntawv pov thawj los tiv thaiv rau cov kav dej sib sib zog nqus tsis zoo ntawm helium sniffing txoj kev.

Tsis yog -Kev Sib Nraus Mechanical Isolation:Triple-offset ncej geometry tshem tawm cov zawv zawg kev sib cuag thaum lub sij hawm tig, suppressing lub rooj galling thiab torque spikes.

Nyob -Loaded Stem Packing:Caij nplooj ntoos hlav- lub zog foob sib txuas ua ke them nyiaj rau kev nthuav dav thermal thiab kab kev co kom ua tau raws li cov cai ntawm kev khiav tawm.

Hard-Faceed Sealing Surfaces:Lub cev lub rooj zaum hardened nrog cobalt-puag alloys tiv taus particle yaig thiab hnyav txhua yam hnav.

Bidirectional Differential kaw -Tawm:Tuav Chav Kawm VI nruj nyob rau hauv tag nrho kev ua hauj lwm siab sib txawv nyob rau hauv ob qho tib si ib txwm thiab rov qab ntws cov lus qhia.

Geometrical Offset Structure:Cov ncej yog offset los ntawm ob lub dav hlau sealing thiab cov yeeb nkab centerline, thaum lub rooj zaum lub khob hliav qab axis yog inclined kom muaj kev sib txhuam -dawb disc kev koom tes.

Dual -Cov ntaub ntawv foob:Laminated stainless hlau nrog saj zawg zog graphite khaubncaws sab nraud povtseg rau cov qauv thermal ranges, los yog cov khoom hlau - mus rau -hlau zaum nrog Stellite overlays rau cov mob hnyav.

Hnyav-Duty One-Piece Shaft:Tsav shafts xam rau qhov siab tshaj plaws tso cai torsional strain nyob rau hauv kev hloov pauv hloov pauv hloov pauv.

Dynamic Compensation Packing:Multi-ring graphite los yog chevron V-ring packing packs tuav nyob rau hauv nruam compressive load los ntawm Belleville disc caij nplooj ntoos hlav stacks.

Protected Journal Bearings:Tus kheej -lubricating stainless hlau bearings nruab nrog thawj cov khoom wipers kom cov txheej txheem cov khib nyiab tawm ntawm ncej kab noj hniav.

Lub valve no tso siab rau cov neeg kho tshuab torque es tsis yog cov dej siab kom ua tiav kev sib cais nruj. Thaum lub sij hawm kaw, lub disc mus ncig tsis tau lub rooj zaum kom txog rau thaum kawg ntawm ib tug degree. Applied actuator torque presses lub resilient disc foob nplhaib uniformly mus rau hauv lub conical lub rooj zaum, tsim elastic deformation uas tsim lub nqus tsev vacuum - nruj seal. Thaum qhib, lub disc tam sim ntawd tshem tawm ntawm lub rooj zaum lub nplhaib, tshem tawm kev hnav los ntawm cov nplaum los yog cov khoom siv polymerized nyob rau hauv lub tshuab nqus tsev.

Wafer kev twb kev txuas:Unflanged compact lub cev drilled rau alignable pass-los ntawm studs; fits nruj nreem txwv ntawm kab flanges.

Lug txuas:Threaded bolt qhov sib piv thoob ntiaj teb flange qauv; tso cai rau kev tuag- kawg cais nyob rau hauv lub tshuab nqus tsev lossis siab.

Flanged kev twb kev txuas:Muab ob npaug rau-flanged lub cev ua raws li lub ntsej muag luv thiab ntev-rau- ntsej muag qauv; resists hnyav yeeb nkab kev nyuaj siab.

Butt-Kev Txuas Txuas:Direct welding xaus tshem tawm cov neeg kho tshuab flange cov pob qij txha nyob rau hauv cov kab mob los yog flammable vapor kab.

Manual Control:Cov kab cab cab uas muaj nyob hauv nruab nrog qhov ntsuas qhov pom, qhov kawg - nres, thiab padlockable handwheels.

Pneumatic kev ua haujlwm:Muab ob npaug rau- ua yeeb yam lossis caij nplooj ntoos hlav- rov qab scotch-yoke thiab khib-thiab- pinion actuators haum nrog cov ntse positioners thiab txwv cov keyboards.

Kev ntsuas hluav taws xob:On -off lossis modulating electric drives featuring weatherproof enclosures, interal local controls, and digital fieldbus protocols.

Hydraulic tswj:Siab -torque hydraulic systems engineered rau ceev- ua haujlwm kaw thaum muaj xwm txheej ceev.

Condenser Vacuum Systems:Tswj tsis yog- cov kav dej tshem tawm cov roj condensable ntawm cov pa turbine exhausts.

Polysilicon Refining:Tuav cov roj av thiab cov kab rov qab trichlorosilane raug rau kev caij tsheb kauj vab uas muaj cua sov thiab kev sib sib zog nqus tsis zoo.

Tshuaj Distillation & Evaporation:Cais lub tshuab nqus tsev fractionating towers, nyias -film evaporators, thiab hnyav regeneration kab.

Gas cais chav tsev:Tswj lub siab- viav vias adsorption li qub thiab cryogenic cua sib cais cov thawv txias.

Vacuum Thaum tshav kub kub kho:Tswj cov cua sov cua khiav tawm thiab nqus cov kab degassing hauv kev ua haujlwm metallurgy.

Kauj ruam 1: Xaiv Packing System Raws li Kub
Qhia tawm nyob -loaded PTFE chevron packing rau xov xwm hauv qab 200℃. Xaiv cov tuag- molded graphite nrog Belleville caij nplooj ntoos hlav stacks rau kub tshaj 200℃mus txog 550℃.

Kauj Ruam 2: Txhais Cov Lus Qhia Nqus Tsev
Txheeb xyuas seb puas yog sub- atmospheric siab ua nyob rau sab ncej los yog sab disc kom optimize actuator sizing thiab dynamic torque xam.

Kauj ruam 3: Xaiv Sealing Surface Trim
Xaiv laminated SS316 thiab graphite seals rau cov txheej txheem txheej txheem. Qhia kom meej cov khoom hlau-rau- hlau Stellite 6 overlays rau siab- voj voog kev khiav hauj lwm los yog abrasive khoom entrainment.

Kauj ruam 4: Thov Actuator Safety Margin
Siv qhov kev nyab xeeb yam tsawg kawg nkaus ntawm 1.3 tshaj qhov siab tshaj plaws dynamic so-torque rau cov pa huv si, thiab 1.5 txog 1.8 rau cov ntawv siv lub tshuab nqus tsev qias neeg.

Txhua lub valve tsim tau dhau los ntawm tus kheej kev kuaj xyuas ua ntej xa:

Hydrostatic & Pneumatic Kev Ntsuas:Plhaub hydro- kuaj rau 1.5 npaug ntawm qhov ntsuas nominal; Lub rooj zaum pneumatic kuaj raws li ISO 5208.

Helium Mass Spectrometer Sniffer Test:Tshawb xyuas siv cov txheej txheem nqus tsev vacuum raws li EN 1779 kom ntseeg tau tias tag nrho cov xau tseem qis dua 1 x 10^-6 mbar L / s.

Dynamic Torque Mapping:Sau hla 0 txog 90℃rotation ntawm automated test stands.

Cov Khoom Siv Kev Ncaj Ncees:Kev txheeb xyuas cov khoom zoo (PMI) ua rau txhua yam khoom siv hlau, xa nrog EN 10204 3.1 daim ntawv pov thawj tshuaj xyuas.

Tsis yog- tus qauv ntsej muag-rau- lub ntsej muag qhov ntev tsim los hloov cov qub qub qub yam tsis muaj kev hloov kho kav dej.

Extended bonnet designs for cryogenic service or high -kub yeeb nkab rwb thaiv tsev clearing.

Siab -Velocity Oxygen Fuel (HVOF) chromium carbide los yog tungsten carbide coatings rau abrasive nqus kab.

Tag nrho ua raws li NACE MR0175 / ISO 15156 rau qaub roj sub- atmospheric systems.

Cov kuab tshuaj degreasing, ntxuav ultrasonic, thiab ntim huv chav rau siab -purity oxygen lossis semiconductor kev pabcuam.
