Forged Y-Pattern Globe Valve

Lub Forged Y-Pattern Globe Valve koom ua ke ib qho inclined 45-degree qia configuration nrog ib qho khoom poob-forged lub cev. Qhov kev hloov pauv hauv cov duab geometry no txo ​​cov dej turbulence thiab lub siab poob thaum tuav qhov zoo kaw -tawm ntawm lub peev xwm ntawm lub ntiaj teb tus qauv tsim. Tsim los rau cov kev pabcuam hnyav, lub valve no ua tau zoo nyob rau hauv kev nruam throttling, high-pressure chav cais, thiab hnyav thermal shock tej yam kev mob.

45-Degree Inclined Flow Axis:Ncaj- txoj kab ntws txo qis qis (ΔP) thiab cov kua dej yaig piv rau cov qauv T- qauv tsim.

Tso-Forged Lub Cev Tsim:Monoblock forged qauv muab cov khoom hnyav hnyav, tshem tawm cov porosity sab hauv thiab casting flaws.

Conical Plug Disc:Precision-machined disc kom ruaj khov linear throttle tswj thiab kaw ntom ntom-tawm hauv qhov sib txawv siab.

Integral Stellite Rooj:Cobalt-puag alloy hardfacing siv rau disc thiab lub rooj zaum lub cev qhov chaw tiv thaiv hnav, galling, thiab particle cuam tshuam.

Tsawg-Emission Stem Seal:Tuag- tsim graphite packing nrog nyob -loaded caj pas bolts tuav lub active foob compression nyob rau hauv heev thermal cycling.

Lub cev-rau-Bonnet Configurations:Muaj nyob rau hauv Bolted Bonnet rau kev saib xyuas tsis tu ncua, lossis Welded thiab Pressure Seal Bonnets rau kev siab siab.

Tsis yog -Rotating Stem Design:Linear qia ua haujlwm tiv thaiv torsional hnav ntawm lub nplhaib ntim, txuas ntxiv kev ua haujlwm sealing.

Guided Disc Assembly:Hauv qab-coj disc muab kev sib haum xeeb tiv thaiv lub ntsej muag, tshem tawm qia deflection hauv siab - nrawm ntws.

Integral Seat Siv:Hardface alloy welded ncaj qha mus rau lub forged lub cev phab ntsa tshem tawm tej zaum yuav xau txoj hauv qab lub rooj rings.

Kev sib hloov ntawm lub log los yog lub tshuab hluav taws xob ua rau qhov tsis yog -rotating stem down raws 45-degree centerline. Cov kev taw qhia ntsaws disc nqis los hu rau lub rooj zaum ntawm lub cev hardfaced, thaiv txoj kev ntws.

Thaum qhib, lub disc retracts mus rau hauv lub kaus mom kab noj hniav, tag nrho nthuav tawm inclined flow channel. Vim tias cov kua dej dhau los ntawm cov kev hloov pauv hloov zuj zus ntau dua li cov ces kaum sab xis, qhov kev kub ntxhov tseem tsawg, cov phab ntsa hnav yog txo, thiab cov kab siab raug khaws cia.

Handwheel:Standard phau ntawv ua haujlwm nrog impactor log rau siab -pressure sib txawv qhib.

Bevel iav:Ntau-tig iav lub thawv rau txo qis kev tuav haujlwm torque ntawm qhov loj dua valve.

Hluav taws xob Actuator:Ntau -tig hluav taws xob tsav nrog txoj hauj lwm tawm tswv yim modules rau automated tswj loops.

Pneumatic Actuator:Tawm caij nplooj ntoos hlav- rov qab los yog ob npaug - ua haujlwm pneumatic tsav kom ceev - ua haujlwm cais tawm.

Boiler Blowdown Kab:Resistant kua flashing thiab abrasive hnav thaum lub sij hawm siab - kua nyem nyem.

Siab -Steam Loops:Tswj siab -kub kab kab nrog tsawg kawg kab siab poob.

Chemical Feed Systems:Muab qhov tseeb linear metering rau aggressive chemical additives.

Hydrocarbon Refining:Tuav lub rooj zaum nruj nyob rau hauv qhov hnyav nruam thermal cycling.

Geothermal Fluid Lines:Smooth internal contouring txo cov ntxhia nplai tsub zuj zuj hauv lub valve chamber.

Flow Requirements:Txheeb xyuas qhov yuav tsum tau ntws coefficient ($C_v$) tiv thaiv lub hom phiaj poob siab.

Siab & Kub:Match system kev khiav hauj lwm tej yam kev mob nrog ASME B16.34 siab- ntsuas kub ntsuas.

Kev xaiv khoom siv:Qhia txog Carbon Steel rau cov qauv chav ua haujlwm, Alloy Steel rau qhov kub siab tshaj 450 degree, thiab Stainless Hlau lossis Duplex rau cov txheej txheem corrosive.

Hom Bonnet:Xaiv Bolted Bonnet rau cov txheej txheem siab, lossis Siab Foob / Welded Bonnet rau siab -siab thermal shock applications.

Hom kev sib txuas:Xaiv txoj kev sib txuas cov yeeb nkab (Socket Weld, Threaded, Flanged) raws li cov kab yeeb nkab specifications.

Hydrostatic Pressure Test:Kev sim ntawm 1.5 npaug ntawm kev ua haujlwm siab ntawm API 598.

Pneumatic Seat Test:Nitrogen lub rooj kuaj ntawm 1.1 zaug tsim siab kom paub meej tias xoom xau.

Tsis yog-Kev kuaj xyuas kev puas tsuaj:Dye penetrant testing on weld overlays thiab magnetic particle soj ntsuam ntawm forged lub cev.

Kev txheeb xyuas cov khoom zoo:X-ray fluorescence tsom xam ntawm tag nrho cov hlau alloy hlau ua ntej tso tawm.

Cov ntaub ntawv pob:EN 10204 3.1 Cov Ntawv Pov Thawj Cov Khoom Siv, Cov Ntawv Qhia Txog Kev Ntsuas Hydrostatic, NDE Cov Ntaub Ntawv, thiab Daim Ntawv Pov Thawj Ua Raws Cai.

Kab Extensions:Kev cai ntev extensions rau insulated los yog cryogenic installations.

Nyob -Loaded Packing:Caij nplooj ntoos hlav ntxhua khaub ncaws tsim los tswj lub caj pas packing siab nyob rau hauv fluctuating thermal tej yam kev mob.

Cov rooj zaum tshwj xeeb Overlays:Customized hardfacing alloys muaj rau cov kev xav tau ntawm cov kua dej.

Locking Devices:Padlock attachments kom ruaj lub valve nyob rau hauv tag nrho qhib los yog kaw tag nrho txoj hauj lwm.
